ROE MC7H (In touring Frames and Dollies)
Module MC-7H
Pixel Pitch 7.5mm
Max. Brightness Calibrated 5,000nits
Panel Dimension
(Touring Frame)
600 x 600 x 95mm 23.6" x 23.6" x 3.7"
600 x 1200 x 95mm 23.6" x 47.2" x 3.7"
Panel Resolution (H x V) 80 x 80
Weight Per Panel
(Light Frame) / 9.52kg; 20.99lbs
(Touring Frame) 14.80kg; 32.63lbs
Power Consumption 300W / 150W Max/Average 420W / 210W(HB)
Transparency Solid
Serviceability No No No No No
Curving (Concave & Convex) Concave 10°~Convex 10° Concave 10°~Convex 10° Concave 10°~Convex 10° Concave 10°~Convex 10° Concave 10°~Convex 10°
Max. Hanging (panels) 20
Max. Stacking (panels) 8
LED Configuration SMD 3535 Black(HB)
Viewing Angle Vertical 120°/ Horizontal 140°
Multiplexing 5 Static
Refresh Rate 2000Hz
Gray Scale 16bit
Frame Material Magnesium Alloy Magnesium Alloy Magnesium Alloy Magnesium Alloy Magnesium Alloy
IP Rating Outdoor
Certifications CE, ETL,
